10
1. Install the magnetic closing seals on the
sliding glass panes.
2. Install the sealing gasket between fixed
glass and sliding door.
Note: there is a higher and a lower gasket
supplied, the lower one goes in the fixed
glass, the higher one in the sliding glass.
1. Check the plumbness, drill holes from the
inside to secure the shower wall to the
profiles, to the wall with 8x16 screws and
to the corner profile with 6x20 screws.
IMPORTANT: maximum fixed glass adjust-
ment 2.5 cm.
Note: A total of 6 holes must be drilled, 2 ho-
les per profile, 1 at the top and 1 at the bot-
tom.
2. Cover the wall profile of the fixed wall
with the aluminium cover to conceal the
fixing screws and to protect them from
water.
3. Cover the screws of the angle profile with
screw caps.
G
F
1
2
1
2
8*16
B
6*20
3
60
