1
1. Insert the flat gasket between the fixed
glass and the aluminium profile (inner
side).
2. Install the end stop on the top and bot-
tom rails. Use the supplied 8x12 screws,
otherwise you risk drilling holes in the vi-
sible side of the slide rail.
8*12
8*12
H
2
2
1
3
1. Install handles (hole on insi-
de).
2. Install the cover caps at the
top of the aluminium profiles.
3. Siliconise the outside of the
shower enclosure around the
entire perimeter and wait 24
hours.
2
61
