Laney CP10 - Model CP12 Overview; CP12 Front Panel Controls; CP12 Rear Panel Information

EXPLANATION OF TERMS
8
1
4
MIC:
TREBLE:
BASS:
EXTERNAL SPEAKER:
POWER:
XLR iInput for LO impedance
microphones (200-600Ohm).
Adjusts the monitors HI
frequency response.
MIDDLE: Adjusts the monitors MID
frequency response.
Adjusts the monitors LO frequency
response.
Output socket
for connect further un powered Laney
monitor such as CM10, CM12 or CM15.
Power On/Off switch.
LINE:
LINK:
VOLUME:
Jack input socket for all line level
signals e.g.: Keyboard, mic or drum
machine.
Socket for connecting additional
power monitor or power amplifier.
Controls the overall listening
level of the monitor.
CP Manual
2
9
3
5
6
7
1
2
3
4
5
6
7
