SPECIFICATIONS
Laney
Page
15 / 16
This product conforms to the requirements of the following European Regulations, Directives & Rules:-
CE Mark (93/68/EEC), Low Voltage (72/23/EEC), EMC (93/68/EEC),
RoHS (EU2002/95/EC), WEEE (EU2002/96/EC)
In order to reduce environmental damage, at the end of its useful life, this product must not be disposed of along with normal
household waste to landfill sites. It must be taken to an approved recycling centre according to the recommendations of the
WEEE (Waste Electrical and Electronic Equipment) directive applicable in your country.
Supply Voltage ~100V, ~120V, ~220V, ~230V, ~240V 50/60Hz Factory Option
Mains Fuse (~220V>240V = T2A L 250V) (~100>120V = T5A L 250V)
HT Fuse T1A L
Power Consumption 200W
Output Power Rating 50W
Features Pure Class A/B Valve tone
2xEL34B-STR Power Tubes (Matched Set TAD)
4x12AX7 Preamp tubes (Premium TAD ECC83)
Hi & Lo Gain Inputs
Rugged construction
Selectable FX Loop with Level Control (Switchable Sidechain/Insert/Bypass) (Nominal 500mV Level)
Footswitchable Yes, Channel (FS1 Optional)
EQ Passive Bass, Middle and Treble
Resonance Switch
Presence
Switchable Extra Drive Stage
Input Impedance 1MOhm/47pF
Size
Unit Weight 20Kg
Loudspeaker Outputs 1*16 Ohm
1*8 Ohm 2*16 Ohm
1*4 Ohm 2*8 Ohm
(H*W*D) 260*675*250
