HI INPUT: This input provides maximum gain from the instrument to the pre amp. Is is extremely useful for
guitars with single coiled or low gain humbucker type pickups. Use of high gain pickups in this input
may drive the preamp too severly, causing a "mushy" output
LO INPUT: This input is attenuated down approximately 6dB from the Hi input. It is useful in obtaining output
that is "tight" not "mushy" from high end gain humbucker type pickups.
GAIN: This adjusts the level of overdrive in the preamp. At low levels the preamp runs very clean, at levels up to
7 the gain and distortion increases smoothly. When the control is set beyond 7 another stage of gain is introduced
resulting in a saturated valve sound.
BRIGHT SWITCH: Adds brightness and sparkle to the upper frequencies of the amplifier. These upper
frequencies are more noticable at low gain settings.
BASS: Controls the low frequency EQ in the preamplifier.
MIDDLE: Controls the mid frequency EQ in the preamplifier.
TREBLE: Controls the high frequency EQ in the preamplifier.
VOLUME: Sets the overall listening level of the amplifier.
POWER FUSES: This fuse protects the AC power of the overall amplifier. USE ONLY THE CORRECT SIZE
AND RATING OF FUSE AS SPECIFIED ON THE PANEL. If a fuse blows or fails and a replacement of the
same size and rating is installed and it in turn blows, the amplifier has suffered a malfunction internally and needs
immediate service from a qualified technician. DO NOT TRY USING A FUSE OF HIGHER RATING. Using a
fuse that is too large in current rating may cause serious, irrepairable damage to the amplifier and presents a
serious fire hazard.
