FW-8894 User Manual
Form Factor
1U Rackmount
Platform
Processor Options
2x Intel Xeon E5-2600 v3 Series on
LGA2011-R3 (Haswell-EP)
Chipset
Intel C612 chipset
BIOS
AMI BIOS 128Mb
System Memory
Technology
DDR4 2133 MHz registered DIMM
Max. Capacity
512 GB
Socket
16x 288-pin DIMM
Networking
Management Port
1x RJ45 GbE port, shared with IPMI
Bypass
Depending on Ethernet module
specifications (support Lanner Gen 3 bypass)
Ethernet Ports
3x GbE RJ45 Intel® i211
Controllers
1x Intel® i210AT
Ethernet Modules
up to 4 slim type modules
Security Acceleration
Intel ColetoCreek 8925
LAN Ports
Up to 32 GbE ports, depending on
modules installed
OS Support
Windows 7, 2008 Server, Linux kernel 2.6 or
later
I/O Interface
Reset Button
1x reset button
Software reset by default
USB
2x USB 2.0
IPMI via OPMA Slot
OPMA socket
Storage
Drive Bays
1x 3.5” or 2x 2.5” SATA HDD/SSD
NAND Flash
1x CFast
Expansion
PCIe
4x PCIe*8 connectors for front NIC
2xPCIe*16 Zd connectors for backplane
1x PCIe*8 connectors for riser card
Miscellaneous
LCD Module
1x character type LCM with 4x keypads
(graphic optional)
Watchdog
YES
Internal RTC with Li Battery
YES
Cooling
Processor
2x CPU heat-sink with fan duct
System
4x independent hot-swappable cooling fans
with smart fan control
Environmental Parameters
Temperature
0~40ºC Operating
-20~70ºC Non-Operating
Humidity (RH)
5~90% Operating
5~ 95% Non-Operating
System Dimensions
(WxDxH)
438 x 44 x 630 mm
Weight
18 kg
Power
Type/Watts
100-240V/ 47-63Hz/ 10-5A
Input
AC 100~240 V@47~63Hz
Certificate & Compliance
CE Class A, FCC Class A, RoHS
