Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 118
clrscrn
Clears the screen.
default priority
Restores the default value of the priority (Excellent Effort).
exit
Exits to the next higher level.
mac address <hexadec-
imal>
Sets the filter MAC Address. Each byte is represented by two adjacent hex digits. Bytes
may run together or be separated by optional punctuation: 123ABC "12 3A BC" 12,3A,BC
12.3a.bc 12:3a:bc Note that quotes must enclose the value if it contains spaces.
network <text>
Sets the filter Network.
no mac address
Removes the filter MAC Address.
no network
Removes the filter Network.
no ports
Removes the filter Port.
ports <text>
Sets the filter Port.
priority background
Sets the priority to Background. Bandwidth allocated is 5%-100%.
priority best effort
Sets the priority to Best Effort. Bandwidth allocated is 10%-100%.
priority critical applica-
tions
Sets the priority to Critical Applications. Bandwidth allocated is 15%-100%.
priority excellent effort
Sets the priority to Excellent Effort. Bandwidth allocated is 10%-100%.
priority internetwork con-
trol
Sets the priority to Internetwork Control. Bandwidth allocated is 5%-100%.
priority network control
Sets the priority to Network Control. Bandwidth allocated is 5%-100%.
priority video
Sets the priority to Video. Bandwidth allocated is 20%-100%.
priority voice
Sets the priority to Voice. Bandwidth allocated is 30%-100%.
show
Shows the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
write
Stores the current configuration in permanent memory.
filter 1 (config-wlan-qos-filter:wlan0:1) level commands
clrscrn
Clears the screen.
default priority
Restores the default value of the priority (Excellent Effort).
exit
Exits to the next higher level.
mac address <hexadec-
imal>
Sets the filter MAC Address. Each byte is represented by two adjacent hex digits. Bytes
may run together or be separated by optional punctuation: 123ABC "12 3A BC" 12,3A,BC
12.3a.bc 12:3a:bc Note that quotes must enclose the value if it contains spaces.
network <text>
Sets the filter Network.
no mac address
Removes the filter MAC Address.
no network
Removes the filter Network.
no ports
Removes the filter Port.
ports <text>
Sets the filter Port.
priority background
Sets the priority to Background. Bandwidth allocated is 5%-100%.
priority best effort
Sets the priority to Best Effort. Bandwidth allocated is 10%-100%.
priority critical applica-
tions
Sets the priority to Critical Applications. Bandwidth allocated is 15%-100%.
priority excellent effort
Sets the priority to Excellent Effort. Bandwidth allocated is 10%-100%.
priority internetwork con-
trol
Sets the priority to Internetwork Control. Bandwidth allocated is 5%-100%.
priority network control
Sets the priority to Network Control. Bandwidth allocated is 5%-100%.
priority video
Sets the priority to Video. Bandwidth allocated is 20%-100%.
priority voice
Sets the priority to Voice. Bandwidth allocated is 30%-100%.
show
Shows the current configuration.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
