Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 169
priority internetwork con-
trol
Sets the priority to Internetwork Control. Bandwidth allocated is 5%-100%.
priority network control
Sets the priority to Network Control. Bandwidth allocated is 5%-100%.
priority video
Sets the priority to Video. Bandwidth allocated is 20%-100%.
priority voice
Sets the priority to Voice. Bandwidth allocated is 30%-100%.
show
Shows the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
write
Stores the current configuration in permanent memory.
ftp (config-ftp) level commands
clrscrn
Clears the screen.
data port <number>
Sets the FTP server data-port.
default data port
Restores the FTP server data-port to default: 20.
default passive mode
ports
Clears the FTP server number of passive ports.
default passive mode
start port
Clears the FTP server passive mode start port.
default port
Restores the FTP server port to default: 21.
exit
Returns to the config level.
passive mode ports
<number>
Sets the FTP server number of passive ports.
passive mode start port
<number>
Sets the FTP server passive mode start port.
port <number>
Sets the FTP server port.
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
show statistics
Displays the FTP statistics.
state disable
Disables the FTP server.
state enable
Enables the FTP server.
write
Stores the current configuration in permanent memory.
ftp put (config-action-ftp_put:wlan0 link state change) level commands
clrscrn
Clears the screen.
connection <instance>
Enters the next lower level. Specify the instance for the next lower level.
default mode
Sets default of simultaneous connection mode.
exit
Exits to the next higher level.
mode sequential
Sets sequential mode; will stop after first connection that goes through.
mode simultaneous
Sets simultaneous mode; will make all possible connections.
no reminder interval
Clears the FTP Put reminder interval. FTP Put is sent once only.
reminder interval
<minutes>
Sets the FTP Put reminder interval.
show
Shows the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
write
Stores the current configuration in permanent memory.
ftp put (config-action-ftp_put:usb0 link state change) level commands
clrscrn
Clears the screen.
connection <instance>
Enters the next lower level. Specify the instance for the next lower level.
default mode
Sets default of simultaneous connection mode.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
