Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 309
key 3 (config-profile-security-wep-key:default_infrastructure_profile:3) level commands
apply wlan
Try out WLAN settings without saving them to Flash. If the settings do not work, when you
reboot the device, it will still have the original settings.
clrscrn
Clears the screen.
exit
Exits to the next higher level.
key <hexadecimal>
Sets WEP key. Each byte is represented by two adjacent hex digits. Bytes may run togeth-
er or be separated by optional punctuation: 123ABC "12 3A BC" 12,3A,BC 12.3a.bc
12:3a:bc Note that quotes must enclose the value if it contains spaces.
key text <text>
Sets WEP key. Each byte is represented by a single character. Note that quotes must en-
close the value if it contains spaces.
no key
Removes WEP key.
show
Shows the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
write
Stores the current configuration in permanent memory.
key 4 (config-profile-security-wep-key:default_infrastructure_profile:4) level commands
apply wlan
Try out WLAN settings without saving them to Flash. If the settings do not work, when you
reboot the device, it will still have the original settings.
clrscrn
Clears the screen.
exit
Exits to the next higher level.
key <hexadecimal>
Sets WEP key. Each byte is represented by two adjacent hex digits. Bytes may run togeth-
er or be separated by optional punctuation: 123ABC "12 3A BC" 12,3A,BC 12.3a.bc
12:3a:bc Note that quotes must enclose the value if it contains spaces.
key text <text>
Sets WEP key. Each byte is represented by a single character. Note that quotes must en-
close the value if it contains spaces.
no key
Removes WEP key.
show
Shows the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
write
Stores the current configuration in permanent memory.
line 1 (line:1) level commands
auto show statistics
Continuously displays line statistics.
baud rate <bits per sec-
ond>
Sets the line speed. <bits per second> = the speed. Standard speeds include 1200, 2400,
4800, 9600, 19200, and so on.
bluetooth serial <line>
Enters the bluetooth serial level. <line> = number of the line (bluetooth serial port) to be
configured.
clear line counters
Sets the serial counters to zero.
clrscrn
Clears the screen.
command mode always
Sets the current line to always be in command mode.
command mode echo
serial string disable
Disables user-defined serial boot string to be echoed in the CLI.
command mode echo
serial string enable
Enables user-defined serial boot string to be echoed in the CLI.
command mode serial
string
Enables user to enter a custom string at boot time to enter command mode.
command mode serial
string <string>
Sets a string that can be entered at boot time to enter command mode. <string> = text with
possible binary characters. Within [] use binary decimal up to 255 or hex up to 0xFF. Within
{} specify decimal milliseconds time delay.
command mode signon
message <string>
Sets a sign-on message that is sent from the serial port when the device boots and when
the line is in command mode. <string> = text with possible binary characters. Within [] use
binary decimal up to 255 or hex up to 0xFF.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
