Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 316
start wps pin
Starts wi-fi protected setup operation.
status
Show link status
wifi direct go mode disa-
ble
Disables WiFi Direct Group Owner Mode.
wifi direct go mode ena-
ble
Enables WiFi Direct Group Owner Mode.
write
Stores the current configuration in permanent memory.
link (config-ethernet:eth0) level commands
clrscrn
Clears the screen.
credentials <text>
Selects the RSA certificate by configured name.
default duplex
Restores the default duplex setting, which is auto.
default eap-ttls option
Restores the default EAP-TTLS protocol option, which is EAP-MSCHAP V2.
default fast option
Restores the default FAST authentication protocol option, which is MD5.
default fast provisioning
Restores the default FAST provisioning, which is Authenticated
default ieee 802 1x
Restores the default IEEE 802.1x protocol, which is EAP-TTLS.
default peap option
Restores the default PEAP authentication protocol option, which is EAP-MSCHAP V2.
default speed
Restores the default speed setting, which is auto-negotiate.
duplex auto
Sets duplex mode to auto.
duplex full
Sets duplex mode to full.
duplex half
Sets duplex mode to half.
eap-ttls option chap
Sets the EAP-TTLS authentication protocol option to CHAP.
eap-ttls option eap-md5
Sets the EAP-TTLS authentication protocol option to EAP-MD5.
eap-ttls option eap-
mschapv2
Sets the EAP-TTLS authentication protocol option to EAP-MSCHAP V2.
eap-ttls option mschap
Sets the EAP-TTLS authentication protocol option to MSCHAP.
eap-ttls option mschapv2
Sets the EAP-TTLS authentication protocol option to MSCHAP V2.
eap-ttls option pap
Sets the EAP-TTLS authentication protocol option to PAP.
eapol disable
Disables EAPoL Authentication.
eapol enable
Enables EAPoL Authentication
exit
Exit back to interface configuration level
fast option gtc
Sets the FAST authentication protocol option to GTC.
fast option md5
Sets the FAST authentication protocol option to MD5.
fast option mschapv2
Sets the FAST authentication protocol option to MSCHAPv2.
fast provisioning authen-
ticated
Sets the FAST provisioning option to Authenticated.
fast provisioning both
Sets the FAST provisioning option to Both.
fast provisioning unau-
thenticated
Sets the FAST provisioning option to Unauthenticated.
ieee 802 1x eap-tls
Sets the IEEE 802.1x protocol to EAP-TLS.
ieee 802 1x eap-ttls
Sets the IEEE 802.1x protocol to EAP-TTLS.
ieee 802 1x fast
Sets the IEEE 802.1x protocol to FAST.
ieee 802 1x peap
Sets the IEEE 802.1x protocol to PEAP.
inner credentials <text>
Selects the RSA certificate by configured name.
no credentials
Clears the RSA certificate name.
no inner credentials
Clears the RSA certificate name.
no password
Clears the password.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
