Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 86
no email disconnect
Discontinues sending email alerts upon closing a connect mode tunnel.
promote host <number>
Promotes the identified host, exchanging it place with the host above it, to adjust the order
of the defined hosts.
reconnect time <millisec-
onds>
Sets the reconnect time value for tunneling connections established by the device in milli-
seconds. <milliseconds> = timeout in milliseconds.
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
show status
Displays tunnel connect status.
start character <control>
Sets the connect mode start character. The character may be input as text, control, deci-
mal, or hex. A control character has the form <control>C. A decimal value character has
the form \99. A hex value character has the form 0xFF.
write
Stores the current configuration in permanent memory.
connection 1 (config-mach10-connection:1) level commands
clrscrn
Clears the screen.
default host
Restores the Hostname or IP address of Mach 10.
default local port
Clears the local port for Mach10 client.
default mqtt host
Restores the Hostname or IP address of MQTT server.
default mqtt local port
Clears the local port for Mach10 MQTT client.
default mqtt port
Restores the Port of MQTT server.
default port
Restores the Port of Mach 10.
default proxy port
Restores the Port of proxy server.
default proxy type
Restores the default Proxy server type (SOCKS5).
exit
Exits to the next higher level.
host <text>
Sets the Hostname or IP address of Mach 10.
local port <number>
Sets the local port for Mach10 client. When configured, a total of 16 consecutive ports will
be reserved.
mqtt host <text>
Sets the Hostname or IP address of MQTT server.
mqtt local port <number>
Sets the local port for Mach10 MQTT client. When configured, a total of 32 consecutive
ports will be reserved.
mqtt port <number>
Sets the Port of MQTT server.
mqtt security disable
Disables SSL for MQTT.
mqtt security enable
Enables SSL for MQTT.
mqtt state disable
Disables MQTT.
mqtt state enable
Enables MQTT.
no proxy host
Restores the Hostname or IP address of the proxy server.
no proxy password
Restores the password for proxy server.
no proxy username
Clears the user name for the proxy server.
port <number>
Sets the Port of Mach 10.
proxy host <text>
Sets the Hostname or IP address of the proxy server.
proxy password <text>
Sets the password the proxy server.
proxy port <number>
Sets the Port of the proxy server.
proxy type socks5
Sets the Proxy server type to SOCKS5
proxy username <text>
Sets the user name for the proxy server.
secure port disable
Disables HTTPS for Mach10 client.
secure port enable
Enables HTTPS for Mach10 client.
show
Shows the current configuration.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
