Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 97
dress
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
start ip address <IP ad-
dress>
Sets the start IP address of DHCP address pool.
start ipv6 address <ipv6
address/prefix>
Sets the start IPv6 address of DHCP address pool. IPv6 addresses are written in eight
groups of four hexadecimal digits separated by colons, such as
2001:0db8:85a3:0000:0000:8a2e:0370:7334 Network address ranges are written in CIDR
notation. A network is denoted by the first address in the block (ending in all zeroes), a
slash (/), and a decimal value equal to the size in bits of the prefix
state enable
Enables DHCP server.
static leases <number>
Change to dhcpd static lease level.
write
Stores the current configuration in permanent memory.
diagnostics (config-diagnostics) level commands
clrscrn
Clears the screen.
exit
Returns to the config level.
log
Enters the next lower level.
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
write
Stores the current configuration in permanent memory.
disconnect (tunnel-disconnect:4) level commands
clrscrn
Clears the screen.
exit
Returns to the tunnel level.
flush serial disable
Does not flush serial data upon closing a tunneling connection.
flush serial enable
Flushes serial data buffer when a tunneling connection is closed.
flush stop character dis-
able
Forwards the stop character from the Line to the network.
flush stop character ena-
ble
Prevents the stop character from the Line from being forwarded to the network.
modem control disable
Does not watch the modem control pin to disconnect.
modem control enable
Watches the modem control pin and disconnects if it is not asserted.
no stop character
Removes the stop character.
no timeout
Disables disconnect after timeout feature for tunneling sessions.
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
stop character <control>
Sets the stop character. The character may be input as text, control, decimal, or hex. A
control character has the form <control>C. A decimal value character has the form \99. A
hex value character has the form 0xFF.
timeout <milliseconds>
Disconnects when no data has been received on the line (serial port) for the specified
length of time. <milliseconds> = timeout in milliseconds.
write
Stores the current configuration in permanent memory.
disconnect (tunnel-disconnect:3) level commands
clrscrn
Clears the screen.
exit
Returns to the tunnel level.
flush serial disable
Does not flush serial data upon closing a tunneling connection.
flush serial enable
Flushes serial data buffer when a tunneling connection is closed.
flush stop character dis-
able
Forwards the stop character from the Line to the network.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
