Lantronix SGX 5150

Using the Lantronix SGX 5150 Serial Device Server
15
11. Select the Administration tab on the top menu, expand Line and Line1 from the left side and select
Configuration. Here make sure that Protocol is set to “Tunnel” and the Baud Rate is set per the Baud
Rate Setting matrix below in Table 3.
(Figure 21)
Follow the matrix below for the proper setting for your system:
Datalogger
Baud Rate Setting
CR2xx
9600
CR300/CR800/CR1000/CR6/
MLGPS/TM50 & TM30 Robots
115200
SlideMinder
38400
(Table 3)
12. Press Submit at the bottom of the page.
(Figure 22)
