Laser Green Laser - Product Features and Setup; Features and Contents; Assembly and Installation

CONTENTS:
Check the contents of the package and
refer to the following list:
1 Star Night Laser unit with power cord.
Photo sensor for automatic night
activation and 6 hour shutoff timer.
1 Stake mounting system.
1 Floor mount base.
1 Instruction manual.
ASSEMBLY:
1. Remove contents from protective packaging. Save packaging for storage.
2. Check the contents of the package for damage. Do not plug the unit into
an outlet if there is damage to the laser, cords, or timer.
STAKE ASSEMBLY:
1. Connect the ground spike by inserting
into shaft of laser unit.
2. For floor mount, remove stake
and insert the floor base.
INSTALLATION:
1. Insert the Star Night Laser unit and stake into the ground facing the area to be illuminated.
2. Adjust the projection angle of the laser by adjusting the side screw. Loosen screw, adjust,
and then tighten screw. This will adjust the vertical direction (up and down) of the laser projection.
3. Unit can be adjusted in the horizontal direction (side to side) by rotating the unit,
while keeping the spike set.
4. Connect the power cord into a 120v/60hz power outlet or extension cord.
5. Laser will automatically turn off when time ends.
WARNING - DO NOT LOOK INTO LASER LIGHT.
FEATURES:
• Red and Green laser colors
• One button operation
• 8 programs to choose from
1 Static Red
2 Blinking Red
3 Static Green
4 Blinking Green
5. Static Red & Green
6 Blinking Red & Green
7 Red & Green Alternating Blinking
8 Combination Cycle - changes every 10 sec.
• Photo Cell operation
• 6 hour on timer, automatically turns
off for longer laser life
• IP 65 water resistant
• Stake or Floor Mount
• Direct plug in cord, 120v Ac
• ETL approved
• Operating Temp: -22˚F to 86˚F (-30˚C to 30˚C)
• Laser Life up to 5000 hrs
• Laser Class IIIa
1
2
1
2
4
3
On/O
Program
Selection
