To locate TV cables
Connect the TV-coax adapter (6) to a TV socket.
Then use the receiver to search for the line, with the test mode
button (14) held down.
To avoid interference, disconnect the building
telephone service.
!
To locate telephone cables
Connect the RJ 11 adapter (10) to a telephone socket.
Then use the receiver to search for the line, with the test mode
button (14) held down.
6
Subject to technical alterations 01.16
Technical data
Transmitter TX / Receiver RECV
Signal
Multi-frequency pulse
Max. input voltage
20 V DC
Max. rel. humidity
< 85% rH non-condensing
Operating temperature
-10°C…40°C
Storage temperature
-10°C…50°C
Transmitter TX
Max. output current
10 mA
Max. signal voltage
8 Vss (peak-to-peak)
Max. testing length
100 m
Power supply
2 x 1,5 V type AAA
Dimensions
80 x 152 x 46 mm
Weight (incl. batteries)
185 g
Receiver RECV
Max. output current
30 mA
SCAN mode measuring range 0 - 5 cm measuring depth
Power supply
4 x LR44 1,5 V button cells
Dimensions 26 x 148 x 17 mm
Weight (incl. batteries)
45 g
5
14
GB
To avoid interference, disconnect the building TV service.
TV sockets in particular may contain lters that have
a negative effect on measurements. In this case,
remove the TV socket and perform the measurement
directly at the cable.
!
