DistanceMaster Compact
13
Technical Data (Subject to technical changes without notice. Rev18W46)
Precision (typical)* ± 2 mm
Measurement range
(inside)**
0,1 m - 25 m
Laser class 2 < 1 mW
Laser wavelength 650 nm
Operating conditions
-10°C … 40°C, max. humidity 80% rH,
no condensation, max. working altitude
2000 m above sea level
Storage conditions -20°C … 70°C, max. humidity 80% rH
Automatic switch-off 30 sec laser / 3 min device
Power supply 2 x AAA 1.5 Volt batteries
Dimensions (W x H x D) 43 x 110 x 27 mm
Weight (incl. batteries) 100 g
EU directives and disposal
This device complies with all necessary standards
for the free movement of goods within the EU.
This product is an electric device and must be
collected separately for disposal according to
the European Directive on waste electrical and
electronic equipment.
Further safety and supplementary notices at:
http://laserliner.com/info?an=ACF
* measuring distance up to 10 m with strongly reflective target surface and at room temperature.
The measurement deviation may increase by +/-0.2 mm/m for weakly reflective target surfaces.
** at max. 5000 lux
Calibration
The meter needs to be calibrated and tested on a regular basis to ensure
it produces accurate measurement results. We recommend carrying out
calibration once a year.
Information on maintenance and care
Clean all components with a damp cloth and do not use cleaning agents,
scouring agents and solvents. Remove the battery(ies) before storing
for longer periods. Store the device in a clean and dry place.
EN
