LaserLiner LaserRange-Master T4 Pro User Manual

LaserRange-Master T4 Pro
19
Technical Data (Subject to technical changes without notice. 19W43)
Distance measurement
Precision (typical)* ± 2 mm
Measurement range
(inside) **
0.2 m - 40 m
Angle measurement
Measuring range ± 90°
Resolution 0.1°
Precision 0.1°
Laser class
2 / < 1 mW
(EN 60825-1:2014/AC:2017/AC:2017)
Laser wavelength 650 nm
Strahldivergenz < 1.5 mrad
Operating conditions
0°C … 40°C, max. humidity 85% rH,
no condensation, max. working altitude
2000 m above sea level
Storage conditions -20°C … 70°C, max. humidity 80% rH
Radio module
operating data
Bluetooth LE 4.x interface;
Frequency band: ISM band
2400–2483.5 MHz, 40 channels;
Transmission power: max. 10mW;
Bandwidth: 2 MHz; Bit rate:
1 Mbit/s; Modulation: GFSK/FHSS
Automatic switch-off
Dynamic depending on measuring mode:
Laser: 30 s - 5 min
Device: 3 min - 8 min
Power supply 2 x 1,5V LR03 (AAA)
Dimensions (W x H x D) 23 x 100 x 35 mm
Weight 82 g (incl. batteries)
* measuring distance up to 10 m with strongly reflective target surface
and at room temperature. The measurement deviation may increase by
± 0.2 mm/m for greater distances and under unfavourable measuring
conditions such as strong sunlight or weakly reflective target surfaces.
EU directives and disposal
This device complies with all necessary standards
for the free movement of goods within the EU.
This product is an electric device and must be
collected separately for disposal according to
the European Directive on waste electrical and
electronic equipment.
Further safety and supplementary notices at:
http://laserliner.com/info?an=ACZ
EN
** at max. 5000 lux

LaserLiner LaserRange-Master T4 Pro Specifications

General

Accuracy	± 1.5 mm
Laser Class	Class 2
Laser Wavelength	635 nm
Power Supply	2 x 1.5V AAA batteries
Protection Class	IP54
Display	LCD with backlight
Operating Temperature	0°C to +40°C
