LaserLiner MultiFinder Plus - Page 20

20
EN
Always switch off the power supply when working
near electric wires.
!
9
Continuous current monitoring in unshielded wires as soon
as an electrical field is detected.
STUD-SCAN / METAL-SCAN Current monitoring
Technical data
Detection range AC
110 - 230V, 50 - 60 Hz
Operating conditions
0°C ... 40°C, Max. humidity
80% rH, no condensation, Max.
working altitude 2000 m above
sea level
Storage conditions
-20°C ... 70°C,
Max. humidity 80% rH
Power supply
1 x 9 V alkaline battery
(type 6LR 61)
Dimensions (W x H x D)
80 mm x 186 mm x 40 mm
Weight (incl. battery)
230 g
Measuring depth
Wood/metal beam location
(STUD-SCAN)
Up to 4 cm depth
Targeted metal location:
Ferro-Scan/Non-Ferro-Scan
(METAL-SCAN)
Up to 10 cm /
up to 5 cm depth
Targeted location of live
supply lines (AC-SCAN)
Up to 4 cm depth
Location of dead supply lines Up to 4 cm depth
Subject to technical alterations. 23W40
Information on maintenance and care
Clean all components with a damp cloth and do not use
cleaning agents, scouring agents and solvents. Remove the
battery(ies) before storing for longer periods. Store the device
in a clean and dry place.
