LaserLiner MultiMeter-PocketBox User Manual

MultiMeter-PocketBox
11
EN
1
2
3
4
5
6
7
37mm
15mm
E
C
B
AD
F G H I
J
red
black
A Measured value display
(3.5 segments, 1999 digits)
B Negative measured values
C Direct (DC)
D Alternating (AC) variables
E Automatic range selection
F Diode test
G Continuity test
H Actual measurement is
retained
I Low battery charge
J Measurement units:
mV, V, mA, Ohm,
kOhm, MOhm
Display: O.L: Open line/
overow: measuring
circuit not closed or
measuring range
exceeded
1 Rotary switch to set the
measuring function
2 Switch over measuring
function
3 LCD
4 Holder for test prods
5 Hold actual measured
value
6 Measuring contacts:
black „–“, red „+“
7 Test prods
Insertion of batteries / Replacing the fuse
1
Isolate the device from all
current sources before opening
the battery compartment cover.
Do not switch on the device
with the cover open.
