Calibration
The meter needs to be calibrated and tested on a regular basis to
ensure it produces accurate measurement results. We recommend
carrying out calibration once a year.
8
Max. input voltage 250 V AC/DC
Diode test
open circuit voltage 1,5 V
Continuity test
Audible signal if the resistance is < 30 Ω
Open circuit voltage
approx. 0.5V (measuring voltage) for continuity
and resistance measurement (mode)
Input resistance > 10 MΩ (V DC, V AC)
Polarity Sign for negative polarity
LCD
bis 1999 (3 1/2 segments)
Fuse
250 mA/300 V, Ø 5 mm x 20 mm
Overvoltage CAT III - 300 V
Pollution degree 2
Degree of protection
IP 40
Max. rel. humidity
75% rH non-condensing
Operating temperature 0 °C … 40 °C
Power supply 2 x LR44 1,5 V button cell
Dimensions 114 x 56 x 23 mm
Weight (incl. batteries)
101 g
Test standards
EN 61326, EN 61010-1, EN 61010-2-031
Technical data
Function Range Accuracy
DC voltage
200 mV
± (0,8% rdg ± 5 Digits)
2/20/200 V
250 V ± (1,0% rdg ± 5 Digits)
AC voltage
2/20/200 V ± (1,0% rdg ± 5 Digits)
250 V
± (1,2% rdg ± 5 Digits)
DC current
20 mA
± (1,2% rdg ± 5 Digits)
200 mA
AC current
20 mA
± (1,5% rdg ± 5 Digits)
200 mA
Resistance
200 Ω
± (1,2% rdg ± 5 Digits)
2 kΩ
± (1,0% rdg ± 5 Digits)20 kΩ
200 kΩ
2 MΩ
± (1,2% rdg ± 5 Digits)
20 MΩ
± (1,5% rdg ± 5 Digits)
Subject to technical alterations. 07.17
EU directives and disposal
This device complies with all necessary standards
for the free movement of goods within the EU.
This product is an electric device and must be
collected separately for disposal according to
the European Directive on waste electrical and
electronic equipment.
Further safety and supplementary notices at:
http://laserliner.com/info?an=mumepobo
