LaserLiner SensoPilot Pro Quick Start Guide

1 Cover for charger socket
2 Charger socket
3 LED charge display
4 Socket for SensoPilot - remote
display connection cable
OR 12/24V battery cable
5 Laser beam receiver fields
6 LED laser height display (green)
7 LED laser height display (red)
8 LED laser height display (red)
9 Extrem powerful Magnets
for fixing to building machine
10 ON / OFF switch
Precision selection
11 LED laser height display
12 Socket for SensoPilot - remote
display connection cable
13 Socket for 12/24V battery cable
14 Fixing bracket
15 Securing screw for fixing bracket
08
EN
Remote display
for SensoPilot Pro
Order No.
035.00A
Order No.
035.01
10
321
5
6
7
8
9
4
11
12 13
15 14
Safety instructions
Dealing with electromagnetic radiation
– The measuring device complies with electromagnetic compatibility regulations and limit values in
accordance with EMC-Directive 2014/30/EU.
– Local operating restrictions – for example, in hospitals, aircraft, petrol stations or in the vicinity of
people with pacemakers – may apply. Electronic devices can potentially cause hazards or interference
or be subject to hazards or interference.
