08
3
2
ON OFF
TireCheck
TireCheck
1 sec 3 sec
4
GB
Measuring tyre pressure
Checking tread depth
The device starts with the measuring mode last selected.
!
1. Switch on the device. The LC display lights up and shows „0.0“
after 2 seconds.
2. Press button 3 to select the unit of measure psi or bar.
Unit of measure conversion psi (pounds per square inch) and
bar: 1 psi = 0.0689 bar / 1 bar = 14.5038 psi
3. Fit valve connector (1) onto valve. The measured value can
be read off directly.
1. Switch on the device. The LC display lights up and shows „0.0“
after 2 seconds.
2. Move the tread depth gauge (4) corresponding to the tread
depth. The measured value is displayed in mm directly on
the LC display.
In order to preserve the batteries, the measuring device switches off
automatically if it is left idle for 90 seconds.
Auto Off function
