6. General Operation
1. Power
Connect the power cord to the device and to the mains. Make sure that your device is pro-
vided with the correct voltage. Wrong voltage could lead to irreparable damages. Please
nd the correct voltage data in the synoptical table at the end of this manual. Make sure
that the device is not directed to people or inammable objects during installation. To
start the device, connect the interlock bridge, insert the key and switch it on, and switch
the device on. The “Emission - Laser on“ LED at the front side of the device begins to
light up when the device is ready for use.
2. Key Switch
There is a key switch at the back of the laser system. Please plug the key to the switch and
turn it on. The laser device only runs when the key is inserted and switched on. Prevent
misuse! Unplug the key when the laser is unattended to prevent misuse of the sys-
tem.
3. Fuse
There is a fuse at the back side of the device. If the fuse should blow, please exchange
it with a new one. If the problems recurs, please contact your dealer or the Laserworld
service department.
4. Safety Presets
This device has an integrated Scan Safety (SFS). Is the Scan Safety active (on), single be-
ams are prevented. If the Scan Safety is switched o, it is possible to create full power
single beams - be careful!
Operating the laser system with disabled SFS may not be allowed in some countries.
Always ensure that maximum permissible exposure (MPE) is not exceeded in areas
accessible to the public or members of sta.
5. X / Y Inversion (only standard version with ShowNET mainboard)
Use the X, Y buttons to invert the beams resp. patterns on the x-axis and/or y-axis.
6. Colors (not available for DS-1000RGB MK3, nor lasers with FB4 mainboard)
Use the „red“, „green“ and „blue“ knobs to control the intensity per output color channel.
7. Modes / Functions
The dierent operation modes can be selected by using the DIP switches next to the
ShowNET-Display (or FB4) at the back of the device. Any change of the operation mode
for ShowNET devices requires a restart of the device (disconnect power and recon-
nect it again). Do not change any ShowNET-Display settings during operation, as random
and dangerous laser output can occur.
8. Turn device o
To turn o the device, use the power button („OFF“), turn the key to ‚OFF‘ and disconnect
the power cable from the mains.
Find information on how to operate your laser here:
https://www.laserworld.com/en/online-manual
7. Operation Modes
This laser system can be operated in many dierent operation modes.
Information, videos and tutorials are available online!
