latch C2 - Measure Door & Backset

C2 Installation Guide Ve rsion 1.012 13
Select the correct cutsheet according to the door thickness.
Identify if your door has backset A, 2-3/4”, or backset B, 2-3/8”,
with the cutsheet.
1-3/8"1-3/4"
Measure
Preparation
A
B
A
B
A
B
