Hub Installation Guide Ve rsion 1.016 17
PoE
Wiring
For PoE Switches and Injectors
For PoE Splitters
802.3at (Type 2)
12VDC
120mV Peak to Peak or 1%
1.75A
12mm x 2.5mm x 5.5mm
0° - 40°C (32°F - 104°F)
FCC Part 15, EN61000-4-2, EN61000-4-3
Overload and short circuit protection
802.3bt (Type 3) 802.3bt (Type 4)
328ft (100m)
30W+
5e 6 76a 8
10 - 24 AWG
PoE Splitter
12VDC
1.75A (minimum)
PoE Switch/Injector:
802.3at/802.3bt
30W+
Note: Daisy Chain not supported.
PoE Standards
Requirement
Output Voltage
PoE Power
Requirement
Output Voltage
Ripple (Maximum)
Output Current
(Minimum)
DC Barrel Jack
Operating
Temperature
Required
Certications
Additional Features
(Preferred)
Supported
CAT Type
Max Distance
AWG
