© Systeme Lauer GmbH AEG120DR-driver
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○
○○
B
B1.3 PCS connection to the programmable controller
1. Set the DIL-switches 8 and 9 at the rearside of the 090/095/900 PCS to OFF.
Nothing needs to be changed for the 9000 PCS.
2. Load the corresponding software into the programmable controller and set DIL
switches 5 and 6 or the PCS rotary switch correspondingly.
3. Switch off the PCS and then on again (power reset). At least, the ERR LED must
light now.
4. Connect the programming interface of the programmable controller to the PCS
using the PCS 778 cable. If you have activated the SYNC operation, then you
should set the programmable controller restart input to 1.
5. Now, the ERR LED is deactivated at the PCS.
First commissioning
