29
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
© Systeme Lauer GmbH AEG120DR-driver
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○
○○
B
PB3:
The real data access occurs here. Evaluate here the keys, set menus, LEDs, etc..
PB4:
Resets the keys and synchronous words at communication loss. Attach your
measures here.
Used programmable controller areas:
MW 100 FLAG WORD AREA PCS-WORD 0..255
...
MW 355
E 2.1 RESTART INPUT
A3.1 FAULT OUTPUT
M 1.1 TIMER TIME-OUT PROCESSING
M 1.2 RESET TIMER TIME-OUT
M 1.3 EDGE COMMUNICATION LOSS
M 1.4 EDGE RESTART
M 1.5 „
M 1.6 ACCESS AFTER COMM. LOSS
SM 1 AWP is active
SM 2 ON flag
TSW1 TIME-OUT TIMER PRESET VALUE
T 1 TIME-OUT TIMER
PB1 INITIALIZATION
PB2 DATA ACCESS MANAGEMENT
PB3 DATA ACCESS
PB4 COMMUNICATION LOSS
Programmable controller handling software
