© Systeme Lauer GmbHAEG250PX-Expander driver
○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○
D
NAME :ANW_PRO
:U TIM_RES ;timeout timer
:SE T1
:DZB 1000MS
:L K 4
:U RESET ;reset timeout output
:R T1
:= COM_ERR ;timeout -> output a2.1
:***
FB200:
NETWORK: 1
NAME :JOB_SEAR
:***
NETWORK: 2
:BA LA5 ;actual job
NAME :LA5
IN : PJOB_W
OUT : TEMP3_W
:L TEMP3_W
:= ADR_W
:= JOB_W
:= DW_COUNT_W
:L ADR_W ;data address data buffer
:U KH FF00
:ROR K 8
:= ADR_W
:L DW_COUNT_W ;data counter
:U KH F
:= DW_COUNT_W
:L JOB_W ;actual job
:U KH F0
:= JOB_W
:L JOB_W ;read
:== KH 10
:SPB =READ
:L JOB_W ;write
:== KH 20
:SPB =WRITE
:L JOB_W ;and function
:== KH 40
:SPB =AND
:L JOB_W ;or function
:== KH 80
:SPB =OR
READ :BA FB210
NAME :READ_FUN
:SP =A_END
WRITE :BA FB211
NAME :WRIT_FUN
:SP =A_END
AND :BA FB212
NAME :AND_FUN
:SP =A_END
OR :BA FB213
NAME :OR_FUN
A_END :L COUNT_W ;if all jobs done
:<> K 0
:SPB =B_END
:BA FB205 ;update sync word
NAME :AUFT_END
B_END :***
NETWORK: 3
:BE
M1.1 TIM_RES
T1
E2.1 RESET
T1
A2.1 COM_ERR
Signal Symbol
SFB139 LA5
MW3 PJOB_W
MW12 TEMP3_W
MW12 TEMP3_W
MW5 ADR_W
MW6 JOB_W
MW7 DW_COUNT_W
MW5 ADR_W
MW5 ADR_W
MW7 DW_COUNT_W
MW7 DW_COUNT_W
MW6 JOB_W
MW6 JOB_W
MW6 JOB_W
MW6 JOB_W
MW6 JOB_W
MW6 JOB_W
FB210
FB211
FB212
FB213
MW4 COUNT_W
FB205
Printout of the AEG250PX handlingsoftware
