LAUNCH CNC-603A Injector Cleaner & Tester User Manual
21
Parts List of Whole Structure
S/N
Material
Code
Material Name
S/N
Material
Code
Material Name
1
103203716
CNC-603A Back plate
23
103203718
CNC-603A Right strut
2
105022381
CNC-603A Pulse signal
connection
24
103260433
Ultrasonic cleaner 220V
3
103203715
CNC-603A Top cover
25
103230404
CNC-603A Base board
4
102190314
LED light strip
26
104130017
CNC-601/801 Lower
sealing washer φ
40.2*15*3
5
103203727
CNC-603A Wire-wrap
board
27
103200350
CNC series hex socket
sleeve
6
103203726
CNC-603A Left side plate
28
104130016
CNC-601/801 Upper
sealing washer φ
40.2*22*3
7
103203728
CNC-603A Level tube
clamp
29
103240285
Pagoda-shape connector
(straight external
thread),G1/4"",ODφ10
8
103230127
CNC Fuel outlet tube
connector cover
30
103100090
Quick connector female
SH20
9
103240023
Cleaning device connector
PC8-02
31
103250008
CNC-601/801A,
Compression screw 2
10
103040051
External teeth lock
washer,
GB/T862.1-1987,6
32
103250007
CNC-601/801A, Knurled
nut
11
105022454
CNC-603A External
threading pagoda
connector，G1/8, 6mm
33
103230107
CNC-601/801A
Backflushing adjusting
stud 2
12
103030039
Hex nut, GB/T41-2000,M6
34
104110009
CNC-601/801A Glass tube
13
102210216
Switch mode power supply
35
103203717
CNC-603A Light strip
casing
14
103011218
Cross recessed pan head
screw,
GB/T818-2000,M3*6
36
104111813
CNC-603A Rubber guard
ring
15
103203720
CNC-603A Ultrasonic
pressing strip
37
199010182
CNC-603A Axial direction
fuel pressure gauge
16
103203729
Ultrasonic cleaner power
supply holder
38
104020119
CNC-603A Plastic knob
17
103203723
CNC-603A Ultrasonic
base
39
107040117
CNC-603A Operation
panel PC protective film
18
104011211
Integrated charger pad,
20*5
40
103203725
CNC-603A Right side
plate
19
103203724
CNC-603A Ultrasonic
guard
41
102100110
Rocker switch,
R210-C5L-BR
20
103203719
CNC-603A Right strut
42
102160578
Power outlet with safety
card
21
104111812
CNC-603A Silicone button
in cylinder-shaped
43
103203712
CNC-603A Base board
22
103203713
CNC-603A Panel
44
104040951
CNC-603A Blow molding
fuel tank
