- THE NUMBER ON THE SCALE RING CORRESPOND TO AROUND 0.4G OF TRACKING FORCE.
TURNING THE COUNTER WEIGHT INWARD CAN DECREASE THE FORCE, WHILE TURNING THE
COUNTER WEIGHT BACKWARD CAN INCREASE THE FORCE.
LEVEL BALANCE ADJUSTMENT
SET THE ANTI-SKATE KNOB TO “0”. THEN, HOLD THE HEADSHELL’S FINGER-LIFT WITH ONE HAND
AND ACHIEVE “LEVEL BALANCE” BY TURNING THE COUNTERWEIGHT EITHER CLOCKWISE OR
COUNTER CLOCK WISE. “LEVEL BALANCE” MEANS THE TONEARM IS PARALLEL TO THE RECORD ON
THE PLATTER, AND THAT THE TONEARM PIPE SHOULD NOT TILT TOWARDS THE COUNTERWEIGHT
SIDE OF THE HEADSHELL SIDE
TONEARM PROPERLY BALANCED:
COUNTERWEIGHT END IS TOO HEAVY, TURN
THE COUNTERWEIGHT COUNTER-CLOCK WISE
TO ADJUST:
HEADSHELL END IS TOO HEAVY, TURN THE
COUNTERWEIGHT CLOCK-WISE TO ADJUST:
ANTI-SKATING ADJUSTMENT
- TO ADJUST THE ANTI SKATING
MECHANISM, TURN THE ANTI-SKATE
KNOB
- SO THAT THE NUMBER CORRESPONDING
TO THE REQUIRED TRACKING
- FORCE IS OPPOSITE THE INDEX LINE. THE
NUMBERS ON THE ANTI-SKATE KNOB
CORRESPOND TO 1G OF TRACKING
FORCE.
PICKUP SELECTOR
- PHONO EQ / THRU ON SELECTOR IS AT THE BACK PANEL.
- SELECT “PHONO EQ”, INTERNAL PRE-AMPLIFIER WILL
PROCESS AUDIO SIGNAL. TURNTABLE CAN DIRECTLY
CONNECTED WITH A SPEAKER
- SELECT “THRU ON”, AUDIO SIGNAL WILL PASS BY
INTERNAL PRE-AMPLIFIER WITHOUT ANY PROCESSOR.
TURNTABLE HAS TO BE CONNECTED WITH EXTERNAL
PRE-AMPLIFIER FOR MUSIC PLAYBACK.
