Operators Manual
Para
obtener una versión gratis de este manual en español, escriba a la dirección
indicada más abajo. Asegúrese de indicar el modelo y el número de serie de su producto.
Pour obtenir gratuitement une version en français de ce manuel, écrivez à l’adresse
ci–dessous. N’oubliez pas d’indiquer les numéros de modèle et de série de votre produit.
Lawn-Boy Inc., Attn: Parts Dept., 81
1
1 L
yndale A
ve S, Bloomington, MN 55420–1
196.
FORM NO. 3321–750 Rev A
Walk-Behind
Power Mower
GoldPro Series
Model No. 10424, 10525, 10547 — 9900001 & Up

Questions and Answers

  • T
    Terry GordonSep 8, 2025
    What to do if my Lawn-Boy GoldPro engine runs rough?
    • D
      douglasjohnsonSep 8, 2025
      A rough-running Lawn-Boy Lawn Mower engine might be caused by: * A disconnected spark plug wire: Connect the wire to the spark plug. * A faulty spark plug: Check the spark plug, adjust the gap, or replace it if pitted, fouled, or cracked. * A dirty air filter: Replace the air filter element.
  • W
    William GreenAug 23, 2025
    What to do if Lawn-Boy GoldPro Lawn Mower engine starts hard or loses power?
    • N
      Nathan CooleyAug 23, 2025
      If your Lawn-Boy Lawn Mower engine starts hard or loses power, you can try these solutions: * Move the throttle lever to the FAST position. * Drain and refill the fuel tank with fresh gasoline/oil mix. * Clean the gas cap vent hole. * Clean or replace the air filter element. * Clean the mower discharge chute. * Clean the underside of the mower deck. * Clean the spark plug, check the spark plug gap, and replace if damaged.
  • N
    Nathan BradfordAug 25, 2025
    Why does my Lawn-Boy GoldPro Lawn Mower engine not start?
    • R
      Ronald DavidAug 25, 2025
      Your Lawn-Boy Lawn Mower engine might not be starting due to several reasons: * The fuel tank could be empty or contain stale fuel. In this case, drain the tank and fill it with fresh gasoline. If the problem continues, consider contacting an Authorized Service Dealer. * The primer might not have been pushed in. Push the primer in three times. * The wire might not be connected to the spark plug. Ensure the wire is securely connected to the spark plug. * The spark plug could be pitted, fouled, or have an incorrect gap. Inspect the spark plug, adjust the gap if needed, or replace the spark plug if it's damaged.
  • J
    Jeremy AlvaradoAug 27, 2025
    What to do if my Lawn-Boy Lawn Mower engine starts hard or loses power?
    • J
      Joseph WolfAug 27, 2025
      If your Lawn-Boy Lawn Mower engine starts hard or loses power, consider these potential causes: * Stale fuel in the fuel tank: Drain the tank and refill with fresh gasoline. * A plugged fuel cap vent hole: Clean the vent hole or replace the fuel cap. * A dirty air filter restricting airflow: Replace the air filter element. * Clippings and debris on the underside of the mower deck: Clean the underside of the deck. * A faulty spark plug: Check the spark plug, adjust the gap, or replace it if pitted, fouled, or cracked. * Low or dirty engine oil: Check the engine oil level and change the oil if it's dirty or low.
  • P
    Philip LeeAug 27, 2025
    How to fix Lawn-Boy Lawn Mower that won't start?
    • M
      Michelle SweeneyAug 28, 2025
      If your Lawn-Boy Lawn Mower engine won't start, several issues could be the cause. First, ensure the fuel tank isn't empty and the fuel is fresh. If that's not the problem, check that the throttle lever is in the Fast position and that you've pressed the primer three times. Also, make sure the wire is securely connected to the spark plug. Inspect the spark plug itself; if it's pitted, fouled, or the gap is incorrect, adjust or replace it. Additionally, check the fuse and replace it if blown. Finally, if your model has a battery, ensure it's adequately charged.
  • M
    michaelatkinsonSep 22, 2025
    What to do if Lawn-Boy Lawn Mower does not self-propel?
    • K
      Katie AndersonSep 22, 2025
      If your Lawn-Boy Lawn Mower is not self-propelled, it may be due to the self-propel drive cable being out of adjustment or damaged; adjust the cable or replace it if needed. Also, check for and remove any debris under the belt cover.
  • J
    jhopkinsSep 16, 2025
    How to fix uneven cutting pattern with Lawn-Boy Lawn Mower?
    • K
      Karen ReynoldsSep 16, 2025
      To correct an uneven cutting pattern with your Lawn-Boy Lawn Mower, first ensure all four wheels are set at the same height. If the blade is dull, sharpen and balance it. Avoid mowing in the same pattern repeatedly by changing the mowing pattern. Also, clean the underside of the lawn mower deck to remove any accumulated clippings and debris.
  • S
    salvarezSep 18, 2025
    What causes the discharge chute to plug on my Lawn-Boy Lawn Mower?
    • G
      Gwendolyn ReeseSep 18, 2025
      A plugged discharge chute on your Lawn-Boy Lawn Mower can occur for several reasons. Make sure the throttle lever is in the Fast position. If the cutting height is too low, raise it. Avoid mowing too fast, so slow down your pace. Ensure the grass is dry before mowing. Finally, clean the underside of the lawn mower deck to remove any accumulated clippings and debris.
  • S
    Samuel LevineSep 7, 2025
    How to fix uneven cutting pattern with my Lawn-Boy GoldPro Lawn Mower?
    • D
      Dan ChapmanSep 7, 2025
      An uneven cutting pattern with your Lawn-Boy Lawn Mower may arise from: * Uneven wheel height: Ensure all four wheels are at the same height. * A dull blade: Sharpen and balance the blade. * Repetitive mowing pattern: Change the mowing pattern. * Debris buildup: Clean the underside of the lawn mower deck.
  • H
    Harold AndrewsSep 4, 2025
    What to do if Lawn-Boy Lawn Mower will not self-propel?
    • C
      coxmelissaSep 4, 2025
      If your Lawn-Boy Lawn Mower will not self-propel, adjust the self-propelled cable.

Summary

Safety

Safe Operating Practices

Outlines essential safety guidelines for operating the mower to prevent injury.

Assembly

Safety and Instruction Decals

Before Starting

Mixing Gasoline And Oil

Lawn Preparation And Mowing

Operation

Starting Engine

Step-by-step guide on how to start the mower's engine.

Self-propelled Drive

Maintenance

Recommended Maintenance Schedule

A table outlining maintenance tasks and their recommended frequency.

Air Filter

Spark Plug

Blade

Blade Sharpening

Lubrication

Self-propelled Cable

Troubleshooting

Mulch Plate

Storage

Fuel

Engine

Lawn-Boy GoldPro Series Specifications

General IconGeneral
Deck MaterialSteel
Starter TypeRecoil
Mulching CapabilityYes
Bagging CapabilityYes
Side Discharge CapabilityYes
Drive SystemSelf-propelled
Discharge OptionsMulch, Side Discharge
Cutting Height1.25 to 3.75 inches
Wheel Size7 inches (front)
Fuel Tank Capacity0.5 gallons
