LawnMaster CLMF4015K - Page 17

17
ASSEMBLY
Fig. 7 Fig. 8
Notches Rods
INSTALLING AND REMOVING THE GRASS COLLECTION BAG
NOTE: The safety ap is spring operated. Ensure you have a rm grip when opening and closing to avoid
personal injury.
Installing the grass collection bag:
1. Lift the rear safety ap and hold it in position (Fig. 7).
2. Lift the grass collection bag by its handle, and align the rods of grass collection bag with the
notches under rear safety ap (Fig. 8).
3. Release the rear safety ap.
4. Make sure both rods are rmly seated on the notches and the safety ap rests rmly against the top
of the grass collection bag.
Fig. 5
Fig. 6
Grass Collection Bag
Metal Frame
Sleeve
