LawnMaster CLMF4819A - SIDE DISCHARGE CHUTE INSTALLATION; Installing the Side Discharge Chute

17
ASSEMBLY
INSTALLING THE SIDE DISCHARGE CHUTE
Do not at any time make any adjustment to the lawn mower without rst stopping the motor and removing the
safety key. Ensure the mulching plug is tted when using the side discharge chute. Do not t the collection
bag.
The mower is designed to be able to disperse the clippings back to the lawn when the side discharge chute is
tted. Lift the mulching door and insert the side discharge chute by mounting the support hook onto the metal
spring frame. Release the door back down during operation (Fig. 9). This feature is optional and does not
need to be tted at all times.
WARNING
Fig. 9
