4
Step 3
Attach seat plate (D) to the bottom of the seat cushion (F) (with the
front of the seat plate facing the front of seat cushion). Attach by
using two 2-1/4” screws (J) for the front holes of the seat plate (D)
and two 1” screws (I) for the rear holes of the seat plate (D) and
tighten the screws using allen key (N).
*Note: Tighten the screws completely.
Step 4
Insert levers (D1 & D2) of seat plate (D) to the pre-attached
cable lever receivers on the underside of seat cushion (F) (with
the front of levers facing the front of seat cushion). Push down the
key on the receivers to pull out the levers.
*Note: Fix the cable for the seat plate into the plastic clips attached
to the bottom of the seat cushion.
Disassemble the lever
Assemble the lever
Insert
Push
N
J
F
F
D
I
D
D1
D2
To Next Page
