LAZBOY 48951-A - Step 7: Install Plastic Shroud; Step 8: Position Chair Upright

6
Step 7
Put the plastic shroud (H) over the seat plate (D) (with
front of plastic shroud facing the front of seat
cushion). Align shroud posts to holes on bottom of seat
cushion (F) and press into position.
Step 8
Position the assembled chair upright with the seat plate
facing down. Insert the gas lift with telescoping cover (C) into
the center hole of the seat plate (D).
F
H
D
F
D
C
