14
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
The following dimensions can be used to determine the proper location of submerged
conduits in concrete slab installations. All dimensions are made from the outside of the
spa / hot tub. The topside control panel is shown at bottom of the diagram for
reference.
Figure 2 – Conduit Entry Location Reference Points
Model Dimension A Dimension B
Seduce
30” / 76 cm 8” / 20 cm
Table 1 – Conduit Entry Location Dimensions
10. Consider positioning your spa / hot tub out of or adequately protecting it from
the wind. Just as people can get cold on cool / windy days so can your spa / hot
tub. Windy environments can significantly increase operating costs.
11. Consider using an insulating pad. In cold climates, the ground can rob heat from
the spa / hot tub and increase your operating costs. Consider using a suitable,
outdoor insulating pad in such environments.
A
B
