LCI Tri-Fold Sofa - Introduction

Rev: 05.23.2017
Page 2
Tri Fold Sofa Owners and Service Manual
TABLE OF CONTENTS
Introduction 2
Safety Requirements 3
Operation Instructions 3
Preparation 4
Tools Required 4
Back Cushion Replacement Instructions 4
Full Cushion Assembly 4
Cushion Foam 4
Cushion Cover 4
Stationary Back Replacement Instructions 5
Full Stationary Back Assembly 5
Stationary Back Interior Foam 5
Stationary Back Interior Frame 5
Stationary Back Cover 5
Couch Seat Replacement Instructions 6
Couch Seat Assembly 6
Couch Seat Interior Foam 6
Couch Seat Interior Frame 6
Couch Seat Cover 6
Couch Seat Legs 6
Middle Seat Replacement Instructions 6
Middle Seat Assembly 7
Middle Seat Interior Foam 7
Middle Seat Interior Frame 7
Middle Seat Cover 7
V2 Frame Replacement Instructions 7
Front Kick Rail Replacement Instructions 8
Rear Kick Rail Replacement Instructions 8
Arm Insert Replacement Instructions 9
Foot Assembly Replacement Instructions 9
Care and Cleaning 9
Maintenance 9
Warranty 9
Introduction
Our one-piece, steel frame Tri-Fold Sofa requires no spare mattress to store. In just four simple steps, it transforms
into a comfortable bed. Traditional hide-a-beds have uncomfortable mattresses with support bars that can make
sleeping uncomfortable. Air mattress hide-a-beds eliminate the support bar issue, but can be damaged more easily
and become unusable. The Tri-Fold Sofa coverts from sofa to a very supportive, high-density foam sleep surface in
four simple steps. Now campers can actually look forward to sleeping on the couch!
Additional information about this product can be obtained from www.lci1.com/support or by downloading the free
myLCI app. The app is available on iTunes® for iPhone® and iPad® and also on Google Play™ for Android™ users.
iTunes®, iPhone®, and iPad® are registered trademarks of Apple Inc. Google Play™ and Android™ are trademarks of
Google Inc.
