PROPERTIES
LDICOASUB15A
• 15 inch subwoofer for powerful low-end up to 36 Hz
• 118 dB max. SPL and 2400 Watt peak power through highly efficient digital Class D power amplifier
• Optimized bass reflex ports
• DynX DSP with four application presets (three crossover frequencies, cardioid mode)
• Switchable signal polarity and adjustable delay line for up to 10 meters
• 2 x XLR/TRS “combo jack” inputs and 2 XLR Output
• 18 mm rugged plywood housing and heavy-duty grill
• 4 Aluminum handles with ergonomic rubber surface
• Securely stackable with four stacking-grooves
• M20 thread for distance pole
LDICOASUB18A
• 18 inch subwoofer for powerful low-end up to 29 Hz
• 122 dB max. SPL and 2400 Watt peak power through highly efficient digital Class D power amplifier
• Optimized bass reflex ports
• DynX DSP with four application presets (three crossover frequencies, cardioid mode)
• Switchable signal polarity and adjustable delay line for up to 10 meters
• 2 x XLR/TRS “combo jack” inputs and 2 XLR Output
• 18 mm rugged plywood housing and heavy-duty grill
• 4 Aluminum handles with ergonomic rubber surface
• Securely stackable with four stacking-grooves
• M20 thread for distance pole
CONNECTIONS, CONTROL, AND DISPLAY ELEMENTS
1
POWER SOCKET AND FUSE HOLDER
IEC power socket with integrated fuse holder. A suitable power cable is included in delivery.
IMPORTANT NOTE: Only replace the fuse with a fuse of the same type and values. Please note the inscription on the housing. If a fuse trips repeated-
ly, please contact an authorized service center.
2
POWER
On/off switch. The speaker should always be the last device to be switched on in the signal chain, and the first to be switched off.
