SPEZIFIKATIONEN:
LD PLAY SERIES 12“ VERSION 15“ VERSION
Type Bassreflex Bassreflex
LF Transducer 12“ Woofer 15“ Woofer
HF Transducer 1.35“ Compression Driver 1.75“ Compression Driver
Dimensions (mm) 425 x 640 x 365 495 x 760 x 430
Weight (kg) 15 20
Power Output (W RMS)
Peak
150 W + 30 W
350 W + 50 W
180 W + 40 W
390 W + 60 W
Amplification BIAMPING CLASS A / B BIAMPING CLASS A / B
SPL 1W/1m (dB) 97 98
SPL max (dB) 119 121
Frequency range (Hz) 60 - 18.000 55 - 18.000
HF horn dispersion H/V (°) 90 x 45 90 x 45
Indicators / Controls Clip, Power / MP3 Level, Mic Level, Line Level, Master Volume, Treble, Bass, 5-Band Master EQ
Connectors
INPUT: MIC (XLR, 6.3 MM JACK),
LINE (XLR, 2 X RCA)
OUTPUT: LINE (XLR, 6.3 MM JACK)
Features Digital Audio Player ( USB & SD )
