LD PLAY SERIES - Page 46

46
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS
ESPAÑOLPOLSKIITALIANO
LD PLAY SERIES 12“ VERSION 15“ VERSION
Type Bassreflex Bassreflex
LF Transducer 12“ Woofer 15“ Woofer
HF Transducer 1.35“ Compression Driver 1.75“ Compression Driver
Dimensions (mm) 425 x 640 x 365 495 x 760 x 430
Weight (kg) 15 20
Power Output (W RMS)
Peak
150 W + 30 W
350 W + 50 W
180 W + 40 W
390 W + 60 W
Amplification BIAMPING CLASS A / B BIAMPING CLASS A / B
SPL 1W/1m (dB) 97 98
SPL max (dB) 119 121
Frequency range (Hz) 60 - 18.000 55 - 18.000
HF horn dispersion H/V (°) 90 x 45 90 x 45
Indicators / Controls Clip, Power / MP3 Level, Mic Level, Line Level, Master Volume, Treble, Bass, 5-Band Master EQ
Connectors
INPUT: MIC (XLR, 6.3 MM JACK),
LINE (XLR, 2 X RCA)
OUTPUT: LINE (XLR, 6.3 MM JACK)
Features Digital Audio Player ( USB & SD )
SPECIFICATIONS:
