LDARC 200GT - 200 GT Technical Details and Package Contents; 200 GT Configuration Specifications; 200 GT Package List

200GT Configuration
200GT Package list
PNP*1 5x4x3 Prop*5Pairs Motor protector*4
Magic tape*1
Instruction manual*1
Wire*1 M2x6.7*16
Wheelbase:200mm
Input voltage:3~4S Lipo
KK TOWER(2 Layer) 20*20:
F4+OSD
4in1 20A BLheliS
VTX:Q100 VTX(25mW/100mW 16CH)
Camera:CCD600
(600TVL CCD 160 NTSC)
Motor:XT1806-2500KV
Prop:5x4x3
Weight:190g(without receiver and battery)
Recommend battery:4S 1000~1500mAh
above 25C (not include battery)
200GT(with buzzer and LED)
LDARC 200GT Instruction Manual 2017-12-06 8 Pages-Page 2
NOTE: Stop using big pithch propeller , Suggest using small pitch
propeller（LDARC 5*4*3 PROP）, big pithch propeller will cause the
motor to overheat.
