Le Maitre DMX Interface - XLR Pin Assignments; Auxiliary Output Wiring; DMX Interface Pin Configuration

Pin 1.Ground/Return
Pin 2.Compliment(-)
Pin 3. DataTrue(+)
Pin 4.Spare
Pin 5.Spare
Auxilliary Output 1 & 2
D.M.X. Interface
D.M.X. Data In/ Out
L.= 115 VAC Line
N.= 115 VAC Neutral
XLR Pin Assignments:
