8
INSTALLATION
6. Remove the screw-type adjustable feet
from the other side of the unit bottom and
transfer it to the corresponding position
on the opposite side of the unit bottom.
4. Swap the bottom bush and bottom
bush cap of the upper door. The
bottom bush key must be in the
correct position to allow it to be inserted
correctly.
5. Remove the lower screws, hinge bracket
and adjustable feet from the unit bottom.
unscrew unscrew
