LECTRICEBIKES.COM | 602.715.0907 42
To install:
1. Fully insert battery pack into the bicycle
frame with the key removed. The locking
pin will be retracted.
2. Key position shown: UNLOCKED.
Insert the key into the battery through the
hole in the bottom of the frame. Push the
key into the battery and continue pushing
until you have twisted the keys to the
desired position.
3. Key position shown: OFF.
Turn the key clockwise. There will be
one audible click, and the locking pin will
now protrude through the frame. In this
position, the battery pack will be secured
to the frame, but the power will not be
active.
Locking Pin retracted
Locking Pin protruding
through frame
*Point of view from bottom of bike*
NOTE: When the battery is locked, the
locking pin will protrude through the
frame and will be visible. The location
where the locking pin will be visible is
indicated by the arrow pointing to the
circle in the image to the side and below.
