Lectric XPremium User Manual

LECTRICEBIKES.COM | 602.715.0907 44
When unlocking and removing your battery pack from the
frame, take care that it does not fall to impact the ground. If
your battery impacts the ground and is damaged, discontinue
use and contact Lectric eBikes immediately.
How the two battery system works
Your eBike is equipped with a battery isolator that will automatically
switch between two batteries when two are attached. The switching
device will switch to whichever battery has the higher voltage, within
a certain tolerance (1-2%). For example, if you have the primary
battery on the bike at 75% charge, and you load the auxiliary battery
at 100% charge, the bike will use ~25% charge from the auxiliary
battery until both batteries are at around 75% charge. Then it will start
switching back and forth between both batteries draining them at
approximately the same rate.
To install the auxiliary battery:
1. Move the battery pack so
that it is almost aligned
with the mount top to
bottom.
2. Slide the battery onto the
mount.
3. The battery has been
successfully mounted
when you hear it lock into
position.
4. The keys do not have to
be in the lock cylinder in
order for the battery to be
operational.
1
2
3
4

Lectric XPremium Specifications

General

Category	Electric Bicycle
Weight	75 lbs
Frame	6061 Aluminum
Brakes	Hydraulic Disc Brakes
Suspension	Front Suspension Fork
Drive Mode	Pedal Assist and Throttle
Foldable	Yes
Max Load	330 lbs
Charging Time	4-6 hours
Pedal Assist Levels	5 Levels
Kickstand	Yes
Warranty	1-Year Limited Warranty
Battery	48V 14Ah
Battery Placement	Integrated into frame
Top Speed	28 mph
Gears	7-Speed
Lights	Integrated Headlight and Taillight
Display	LCD Display
Throttle	Yes
Headlight	Yes
Taillight	Yes
Range	45-100 miles (depending on conditions)
