12. Status Indicator
This is a full color status indicator. It displays all working status
of the controller. It indicates different events as following:
Blue: normal working.
Short single white flash: new command.
Long single white flash: reach mode or color cycle edge.
Long single yellow flash: reach speed or brightness limit.
Blue flash: dynamic mode paused.
Red flash: overload protected.
Yellow flash: overheat protected.
Operation
13. Using Remote
Please pull out the battery insulate tape before using. The RF
wireless remote signal can pass through barrier. For proper
receiving remote signal, please do not install the controller in
closed metal parts.
14. Pairing New Remote
The remote and main unit is 1 to 1 paired as default. Further
more, one main unit can be paired to 3 remote controllers
and every remote can be paired to any main unit.
Please do following steps to pair new remote:
1). Plug off the power of main unit and plug in again after 5
seconds.
2). Press remote ‘MODE-’ and ‘SPEED-’ key together in 5
seconds after main unit power on.
After this operation, the indicator will flash white for 3 times
to display the command is accepted, the main unit now will
recognize the new remote. Only the latest paired 3 remote
controllers can be recognized.
15. Free Remote Pairing Mode
In some specific cases, the controller unit may need to be
controlled with any remote. Please do following steps for this
free remote pairing mode:
1). Plug off the power of main unit and plug in again after 5
seconds.
2). Press ‘ON’ and ‘PAUSE’ key together in 5 seconds after
main unit power on.
After this operation, the indicator will flash yellow for 3
times to display the command is accepted, the main unit now
will recognize any remote. To pair the main unit back to
specific remote, please repeat the ‘Pairing New Remote’
operation.
6
Specification
Advanced Features
16. Waterproof
There’s waterproof option for this LED controller, please
check with your dealer if your controller is waterproofed. The
waterproofed controller can be used under water within
depth of 30 meters.
Note: The remote receiving sensitivity will decrease when
controller installed under water, please setup the controller
before installing under water.
17. Flicker Free
The standard models work at 1KHz switching frequency which
is already non-flicker at most application. For more strict
requirements, the advanced model works at 8KHz frequency
and is fully flicker free even at fast moving application or slow
motion video. Please check with your dealer if you’re using
the fully flicker free model.
The controller can absorb most unwanted switching
interference, for better performance please avoid to drive
strong inductive effect loads. Especially for fully flicker free
model, please avoid to wire the output in multi turn coil
shape or drive inductive load.
Base on the PWM working mode, This series controllers
switch LED on and off at high speed to achieve displaying
different color and brightness. At some moving application or
video at slow motion, the on-off flicker might be visible.
