www.prolight.co.uk Starlit Dance Floor User Manual
3
Component Cross Reference Chart
Danceoor Size
(excluding edge trim)
2 x 2ft Panels 2ft x 4ft
Panels
4ft
Edge
4ft Edge with
Power Cable
2ft
Edge
Corners (Set of 4
2 x Left, 2 x Right)
PSU (one
per system)
Remote
Pack
Total 4 Sided 3 Sided
8x8ft 4 2 2 6 4 1 4 1 500W 1
10x10ft 5 3 2 10 7 1 2 1 500W 1
12x8ft 4 2 2 10 6 1 4 1 500W 1
10x12ft 6 3 3 12 8 1 4 1 500W 1
12x12ft 6 3 3 15 8 1 4 1 500W 1
14x12ft 6 3 3 18 9 1 4 1 500W 1
14x14ft 7 3 4 21 11 1 2 1 500W 1
16x14ft 6 3 3 25 11 1 4 1 500W 1
16x16ft 8 4 4 28 12 1 4 1 500W 1
18x14ft 7 4 3 28 13 1 2 1 500W 1
18x16ft 8 4 4 32 13 1 4 1 500W 1
18x18ft 9 5 4 36 15 1 2 1 500W 1
20x16ft 8 4 4 36 14 1 4 1 500W 1
20x18ft 8 4 4 41 15 1 4 1 500W 1
20x20ft 10 5 5 45 15 2 4 1 500W 1
22x16ft 8 4 4 40 14 2 4 1 500W 1
22x18ft 9 5 4 45 16 2 2 1 500W 1
24x18ft 8 4 4 50 16 2 4 1 500W 1
22x20ft 10 5 5 50 16 2 4 1 500W 1
22x22ft 11 6 5 55 18 2 2 1 500W 1
24x20ft 10 5 5 55 17 2 4 1 500W 1
24x22ft 10 5 5 61 18 2 4 1 500W 1
24x24ft 12 6 6 66 19 2 4 1 500W 1
26x20ft 10 5 5 60 18 2 4 1 500W 1
26x22ft 11 6 5 66 20 2 2 1 500W 1
26x24ft 12 6 6 72 20 2 4 1 750W 1
26x26ft 13 7 6 78 22 2 2 1 750W 1
28x24ft 12 6 6 78 21 2 4 1 750W 1
28x26ft 12 6 6 85 22 2 4 1 750W 1
28x28ft 14 7 7 91 23 2 4 1 750W 1
30x26ft 13 7 6 91 24 2 2 1 750W 1
30x28ft 14 7 7 98 24 2 4 1 750W 1
30x30ft 15 8 7 105 26 2 2 1 750W 1
32x32ft 16 8 8 120 30 4 4 1 1000W 1
32x34ft 16 8 8 128 26 4 4 1 1000W 1
34x34ft 17 9 8 136 28 4 2 1 1000W 1
36x36ft 18 9 9 153 29 4 4 1 1000W 1
40x40ft 20 10 10 190 33 4 4 1 1500W 1
The danceoor panels are designed to be installed on dry, stable surfaces. All installations must feature complete edge trim
systems to reduce the risk of any trip hazards.
All components including locking mechanisms and electrical contacts should be carefully inspected each time before laying a
starlit oor system. DO NOT assemble and lay a oor system if any components is worn or damaged. Replacement parts can
be obtained from your local retailer or direct from Prolight Concepts.
The danceoor system utilises custom edge connectors to transmit a safe, low voltage power feed from panel to panel.
