2
1x LED TUBE EXT P PIN1 PIN2 PIN3 Iout(mA)
T8 1500 23W OFF ON ON 550
T8 1200 15W OFF OFF OFF 350
T5 HO80 1449 37W ON ON OFF 860
T5 HO49 1449 26W ON OFF OFF 600
T5 HO54 1149 26W ON OFF OFF 600
T5 HE35 1449 18W OFF OF ON 450
2x LED TUBE EXT P PIN1 PIN2 PIN3 Iout(mA)
T8 1500 23W OFF ON ON 550
T8 1200 15W OFF OFF OFF 350
T5 HO49 1449 26W ON OFF OFF 600
T5 HO54 1149 26W ON OFF OFF 600
T5 HE35 1449 18W OFF OF ON 450
Replacement of FL
length (excl. pins)
7)
Storage
temperature (Ts)
8)
Ambient temperature
(Ta) free air
9)
LEDTUBE T5 EXTERNAL HE35 P 18W 8xx 35W:1449mm -20°C … 80°C -20°C … 50°C
LEDTUBE T5 EXTERNAL HO49 P 26W 8xx 49W:1449mm -20°C … 80°C -20°C … 50°C
LEDTUBE T5 EXTERNAL HO54 P 26W 8xx 54W:1149mm -20°C … 80°C -20°C … 50°C
LEDTUBE T5 EXTERNAL HO80 P 37W 8xx 80W: 1449mm -20°C … 80°C -20°C … 50°C
LEDTUBE T8 EXTERNAL P 15W 8xx 36W: 1200mm -20°C … 80°C -20°C … 50°C
LEDTUBE T8 EXTERNAL P 23W 8xx 15W: 1500mm -20°C … 80°C -20°C … 50°C
LED TUBE EXT is a single sided LED TUBE and must be connected (wired) only one side. “DC input” note is mentioned on the LED
TUBE product label. Once installation is completed, please fill out new plate sticker (included in Driver EXT packaging) and stick the
name plate close to tube “DC input” side on the luminaire.
After rewiring, only LED TUBE EXT can be used in this luminaire. The use of traditional fluorescent tubes or other LEDTUBEs is not
permitted anymore. LEDVANCE does not accept any responsibility, warranty or liability when using other types of light sources.
4)
DRIVER LED TUBE EXTERNAL is a multi-watt Driver, therefore the correct output current must be
set before operation by the dip switch on the DRIVER. It is not allowed to operate the LED TUBE
EXTERNAL outside the specified operation current.
5)
Please visit our website for the latest product information and EXTERNAL tube and driver portfolio: www.ledvance.com/ext-system
The operating temperature range of LED TUBE EXT is restricted. In case of doubt regarding suitability of the application the manufac-
turer of this lamp should be consulted. Please find and measure Tc points and max Tc temperatures marked on the product. In case of
multi-lamp luminaire application measure Tc max temperature of all installed lamps. Please use a flexible thermo sensor (e.g. „Type K“).
Please find additional temperature relevant information at product datasheet. Lamp to be used in dry conditions or in a luminaire that
provides protection.
6)
2) CURRENT SETTING
CURRENT SETTING AT DR EXT DALI-P-1X15-37W 220-240 - EAN10: 4058075730632
CURRENT SETTING AT DR EXT DALI P-2X15-26W 220-240- EAN10: 4058075730656
LED TUBE EXTERNAL T5 / T8 P
