Lefroy Brooks CT 8700 - Page 5

10
20 30
40
3.0
2.0
1.0
50
Flow (Litres/minute)
Static Pressure (Bar)
5
TYPICAL FLOW RATES
Note: Balanced pressures shown are applied directly to the hot and cold inlets; flow rates indicated are
free flowing and may vary subject to restrictions created by installation, pipework, layout or application.
The outlet temperature during testing was 38°C.
