9
Bandwidth: CD to -3dB @ 100 kHz
Distortion: < .05% (actual type .025)
Gain: 26dB
Power Supply: 1700VA toroidal transformer and eight 10,000 µF
100 volt capacitors
Noise: More than 100 dB referenced to rated output.
Input Impedance: 50 k ohms unbalanced
Output Impedance: 0.08 ohms from 20Hz to 20 kHz
Slew Rate: 50 Volts/microseconds
Rated Power:
600 Watts/channel, 20 Hz to 20 kHz, into 8 ohms
1200 Watts/channel, 20 Hz to 20 kHz, 4 ohms
Dimensions:
Faceplate: 17”W x 5 1/2”H
Chassis: 16 3/4”W x 6” H x 14”D
Weight: 58 pounds
Current Capability: 90 Amperes peak
